การข้ามแนวเกลียวทวนเข็มนาฬิกาของต้นไม้ไบนารีเป็นการลัดเลาะองค์ประกอบของต้นไม้ในลักษณะที่ว่าหากสำรวจแล้วจะเกิดเป็นวงก้นหอย แต่จะเรียงกลับกัน รูปต่อไปนี้แสดงการเคลื่อนที่ของต้นไม้ไบนารีทวนเข็มนาฬิกาตามเข็มนาฬิกา
อัลกอริธึมที่กำหนดไว้สำหรับการข้ามผ่านแบบเกลียวของไบนารีทรีทำงานด้วยวิธีต่อไปนี้ -
สองตัวแปร i และ j ถูกเตรียมใช้งาน และค่าจะเท่ากับ i =0 และ j =ความสูงของตัวแปร แฟล็กถูกใช้เพื่อตรวจสอบในขณะที่กำลังพิมพ์ส่วน ตั้งค่าสถานะเป็นเท็จในขั้นต้น ลูปทำงานจนถึง i
ตัวอย่าง
#include <bits/stdc++.h> using namespace std; struct Node { struct Node* left; struct Node* right; int data; Node(int data) { this->data = data; this->left = NULL; this->right = NULL; } }; int height(struct Node* root) { if (root == NULL) return 0; int lheight = height(root->left); int rheight = height(root->right); return max(1 + lheight, 1 + rheight); } void leftToRight(struct Node* root, int level) { if (root == NULL) return; if (level == 1) cout << root->data << " "; else if (level > 1) { leftToRight(root->left, level - 1); leftToRight(root->right, level - 1); } } void rightToLeft(struct Node* root, int level) { if (root == NULL) return; if (level == 1) cout << root->data << " "; else if (level > 1) { rightToLeft(root->right, level - 1); rightToLeft(root->left, level - 1); } } int main() { struct Node* root = new Node(1); root->left = new Node(2); root->right = new Node(3); root->left->left = new Node(4); root->right->left = new Node(5); root->right->right = new Node(7); root->left->left->left = new Node(10); root->left->left->right = new Node(11); root->right->right->left = new Node(8); int i = 1; int j = height(root); int flag = 0; while (i <= j) { if (flag == 0) { rightToLeft(root, i); flag = 1; i++; } else { leftToRight(root, j); flag = 0; j--; } } return 0; }
ผลลัพธ์
1 10 11 8 3 2 4 5 7
